DTX step zoom stereo microscope

DSM step zoom stereo microscope

Step zoom Stereo microscope 1X/2X/3X/4X

Sharp stereo erect image over a wide field of view

45°inclined and 360°rotatable binocular head with locked-in eyepiece. The left and right ocular-tube with diopter adjustment±5dp

Three kind of 90° 1×/2×,1×/3×,2×/4×,

Two kinds of objective rotation for selection: DTX11 are rotated by objective cover; DTX21 are rotated by knob

Power supply 110V/60HZ or 220V/50HZ

Product has CE approval

Illumination:L1.Upper reflected halogen light 12V 10W;down halogen light 12V 10W

Upper reflected halogen light 12V10W

Fluorescent tamp 5w for transmitted light and halogen lamp12v/10w for incident light

Fluorescent lamp 5W for transmitted light and halogen lamp 12v/10w for incident light.Brightness is adjustable

It always adopts led lights for the transmission and reflex illumination

Each packed in Styrofoam and in an innerbox,Four sets in one canton

FEATURES
1.Sharp stereo erect image over a wide field of view.
2.45°inclined and 360°rotatable binocular head with locked-in eyepiece.Both ocular-tube with diopter adjustment ±5dp.The interpupillary distance is between 55-75mm.
3.Three kind of 90°rotatable objective for selection:1×/2×,1×/3×,2×/4×
4.Power supply 100V～240V
5.CE approval

ENQUIRY!
分类： , , 标签： , ,
描述

Illumination:
L1:Incident reflected halogen light 12V 10W;Transmitted halogen light 12V 10W,Brightness is adjustable.
L2:Both incident and transmitted light with LED 1W,Brightness is adjustable.
Each set packed in styrofoam box and in inner box.Four sets in one outer carton.

SPECIFICATION

 Model  Eyepiece Objective  Up & Down Mechanism  Base/Working Stage
DSMW SWF10× 1×-2×
1X-3X
2X-4X		 Arm curved style  Fan-shape plain base with Ø95mmWhite/Black Working stage
DSMW-10
DSM-20 Pillar style  Fan-shape plain base with Ø95mm Frosted Glass
DSM-10
Optional accessories：WF5×、SWF10×、WF15×、WF20× Eyepiece,Ring light,Darkfield Attachment，Jewel Tweezer

OPTICAL DATA

Objective  Eyepiece
WF5× SWF10× WF15× WF20× Working Distance(mm)
Magnification
Field of view
(mm)		 Magnification
Field of view
(mm)		 Magnification
Field of view
(mm)		 Magnification
Field of view
(mm)
1×  5×  20.0 10×   22.0 15×   15.0 20×   10.0 100
2×  10× 10.0 20×   11.0 30×   7.5 40×   6.5
1×  5×   20.0 10×   22.0 15×   15.0 20×   70.0 100
3× 15×  7.0 15×    7.3 45×   5.0 60×   4.3
2× 10× 10.0 20×   11.0 30×   7.5 40×   6.5 100
4× 20×  5.0 40×    5.5 60×   3.7 80×   3.2
