TM-80 0.8-8X stereo microscope
Back to products
Next product
HLCD600 stereo microscope

DSM0745 0.7-4.5X stereo microscope

DSM0745 Zoom objective：0.7X-4.5X, zoom ratio: 1:6.4

This series zoom microscope adopts streamline integrated mechanical design,Easy operation,long working distance,clear resolved image,enclosure integrated. The microscope is used extensively world medical research and health care,biology and botany research, and agriculture,as well as in electronic component manufacturing.Specially suited for LED,PCB inspection,pressing plating and electronic component inspection.

ENQUIRY!
分类： , , 标签： , , ,
描述

OUTFIT

Viewing head  inclined at 45º
Zoom ratio 1：6.4
Eyepiece WF10X/20mm
Objective 0.7x-4.5x
Magnification 7x-45x
Interpupillary distance 55-75mm
Working distance 100mm
Working Stage φ95mm Frosted glass & White/Black Working stage
Height of Pillar 300mm
travel distance 100mm
Diameter of Scope Holder φ76mm

OPTICAL DATA

Eyepiece Standard spec Auxiliary Objective
0.5X 1.5X 2X
Working Distance
100mm		 Working Distance
165mm		 Working Distance
45mm		 Working Distance
30mm
Magnification Field of view mm Magnification Field of view  mm Magnification Field of view mm Magnification Field of view mm
WF10X/
20mm		 7X 28.6 3.5X 57.1 10.5X 19 14X 14.3
45X 4.4 22.5X 8.9 67.5X 3 90X 2.2
WF15X/
15mm		 10.5X 21.1 5.25X 42.8 15.75X 14.3 21X 10.7
67.5X 3.3 33.75X 6.7 101.25X 2.2 135X 1.7
WF20X/
10mm		 14X 14.3 7X 28.6 21X 9.5 28X 7.1
90X 2.2 45X 4.4 135X 1.5 180X 1.1

SPECIFICATION  LIST

Specification  Model
Parts Specification DSM0745 DSM0475-3 DSM0745W DSM07453W DSM0745P
Eyepiece WF10X20mm ● ● ● ● ●
WF15X15mm ○ ○ ○ ○ ○
WF20X10mm ○ ○ ○ ○ ○
Binocular DSM0745 ● ● ●
Trinocular DSM0745-3 ● ● ○
Auxiliary
Objective		 0.5X/165mm ○ ○ ○ ○ ○
1.5X/45mm ○ ○ ○ ○ ○
2X/30mm ○ ○ ○ ○ ○
Stand DSM ● ●
DSMW ● ●
TD-1 ○ ○ ○ ○ ○
TD-2 ○ ○ ○ ○ ○
DSMP ●
Photographic device PH ○         ○
CCD Mount CTV        ○         ○ ○
Jewel Tweezer I/II ○ ○ ○ ○ ○
Darkfield
Attachment		 ASC ○ ○ ○ ○
Incident Light Bowl Shape Halogen Lamp
12V10W		 ● ●
Transmitted
Light		 Halogen Lamp
12V10W		 ● ●
LED Incident Light 1W ● ●
LED
Transmitted Light		 1W ● ●
Ring light RFL ○ ○ ○
Package Styrofoam +carton box ● ● ● ● ●
  • Standard  ○  Optional
