Fixed zoom: 2X or 4X
The depth of field is the value of parsing images if you user 1/2″ CCD camera and monitor for level 320 line
(imaging surface concessional confusion circumference:40)
Resolution is the theory resolute on of wavelength in 550nm
| Model | Magnification | W.D mm | Depth of field | Resolution | TV | Largest compatible CCD | Mount |
| DXT2-WS50T | 2x | 49.7mm | 0.4mm | 6.7 µm | <0.l% | 1/2″ | C Mount |
| DXT2-WS23T | 2X | 23.2mm | 0.28mm | 4.8 µm | <0.04% | 1/2″ | C Mount |
| DXT2-WS30T | 2x | 29.5mm | 0.4mm | 6.7 µm | <0.l% | 1/2″ | C Mount |
| DXT4-WS50T | 4X | 49.6mm | 0.14mm | 4.8 µm | <0.2% | 1/2″ | C Mount |
| microscope function | Compound |
|---|
ALL PRICE MIC TECH QUOTED IS EX-WORK PRICE.
OTHER PRICE INCLUDING SHIPPING WILL BE QUOTED UPON REQUEST.
