MIC TECH K serials Infinite (Plan) fluorsecent f′=200mm super N.A lens
| Mag. | Model | NA | WD(mm) | f’ (mm) | R (μm) | DF(μm) | on object(mm) | on image(mm) | Screw |
| 10x | Fluorescence-10X | 0.40 | 3.6 | 20.0 | 0.74 | 1.65 | 2.2 | 22.0 | 0.8” |
| 20x | Fluorescence-20X | 0.75 | 0.6 | 10.0 | 0.45 | 0.59 | 1.1 | 22.0 | 0.8” |
| 40x | Fluorescence-40X | 0.95 | 0.17 | 5.0 | 0.35 | 0.37 | 0.55 | 22.0 | 0.8” |
| 100xWater | Fluorescence-100X(W) | 1.20 | 0.16 | 2.0 | 0.28 | 0.23 | 0.22 | 22.0 | 0.8” |
| 100xOil | Fluorescence-100X(O) | 1.35 | 0.08 | 2.0 | 0.25 | 0.18 | 0.22 | 22.0 | 0.8” |
