MIC-300i Series Biological Microscope Outfits
| Items | Specification | MIC-302i | MIC-303i |
| Eyepiece | WF10X/20mm | ●● | ●● |
| WF16X | ○○ | ○○ | |
| Infinity Objective | ECONOMIC PLAN 4X/0.10 | ● | ● |
| ECONOMIC PLAN 10X/0.25 | ● | ● | |
| ECONOMIC PLAN 40X/0.65(S) | ● | ● | |
| ECONOMIC PLAN 100X/1.25(S，Oil) | ● | ● | |
| PLAN 4X/0.10 | ○ | ○ | |
| PLAN 10X/0.25 | ○ | ○ | |
| PLAN 20X/0.40(S) | ○ | ○ | |
| PLAN 40X/0.66(S) | ○ | ○ | |
| PLAN 60X/0.80(S) | ○ | ○ | |
| PLAN 100X/1.25(S，Oil) | ○ | ○ | |
| PLAN 100X/1.15(S，Water) | ○ | ○ | |
| Observing Head | Seidentopf Binocular Head, Inclined 30°,
Rotatable 360°, Interpupilary Distance: 50-75mm |
● | |
| Seidentopf Trinocular Head, Inclined 30°,
Rotatable 360°, Interpupilary Distance: 50-75mm |
● | ||
| 3MP built in integrated digital head | ○ | ||
| 5MP built in integrated digital head | ○ | ||
| Nosepiece | Quadruple nosepiece | ● | ● |
| Mechanical Stage | Size 125mmX120mm, Travel Range:76mmX30mm,
Scale: 0.1mm |
● | ● |
| Size 145mmX140mm, Travel Range:76mmX52mm,
Scale: 0.1mm, Two Slide Holder |
○ | ○ | |
| Abbe Condenser | N.A.1.25，With iris Diaphragm | ● | ● |
| Coaxial Coarse and
Fine Focusing Knobs |
Coarse Focusing Travel Range: 25mm
Fine Focusing Travel Range: 2µm/division |
● | ● |
| Aspheric Illumination | 3W LED Illumination，Voltage: 100V-240V | ● | ● |
| Dark Field Unit | Dark Field Ring (Dry, N.A.0.9) | ○ | ○ |
| Polarizing Unit | Analyzer, Polarizer | ○ | ○ |
| C-mount | 1×C-mount（Available for Digital Photography） | ● | |
| 0.5×C-mount（Available for Digital Camera） | ○ | ||
| Cable roller | ● | ● | |
MIC-300id320/ MIC-300id500 Integrated Digital Microscope Specification:
| Model | MIC-300id320 | MIC-300id500 |
| Digital Chip | 3.2MP, 1/2 “, color CMOS | 5MP, 1/2.5 “, color CMOS |
| Resolution | 2048×1536 Pixels（Maximum） | 2952×1944 Pixels（Maximum） |
| Frame Rate | 15～30 fps | 15～30 fps |
| C-mount | 0.5× | |
| Data
Transmission |
USB2.0，Transmission rate: 480mps，external power supply is not necessary | |
| Operating
System |
Available for Windows 2000 / XP / 7 | |
| Image Analysis
Software |
Digital Image Analysis software for microscope | |
| Integrated body with digital head, dust-proof, moisture proof and anti-demolition | ||
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to
make design modification and changes without notice.
