TGT-L 0.65-4.5X stereo microscope
Back to products
Next product
MIC-700 0.8-5.6X stereo microscope

MIC-600 0.67-4.5X stereo microscope

Zoom objective：0.67X-4.5X, zoom ratio: 1:6.7

ENQUIRY!
分类： , , 标签： , , ,
描述
Item Specifications
Microscopy body MIC-645 MIC-660 MIC-645TR
MIC-645 Magnification 0.67x ~ 4.5x
MIC-660 Zoom ratio 6.7 : 1
MIC-645TR Working distance 110mm
Tube inclination

angle

 45° 60° 45°
Interpupillary Left / right interlocked
distance adjustment Adjustment range : 55 to 75mm
Video camera

adaptability

 – C-mount(0.5x built in)
Click stop – Click stop for each zoom

magnification: On-Off

switching possible
Auxiliary objective lens Mounting by screwing into the thread at the bottom

of frame(M48 thread x0.8)
Stand MIC-ILST6 MIC-ILST6
MIC-ST6 Standard large stand LED reflected / transmitted

illumination large stand
MIC-ILST6 Frame installation Mounting diameter : 76mm
Focusing

adjustment

 Knob rotation tension adjustment
Focusing stroke:120mm
Stage plate MIC-SPG MIC-SPG
MIC-SPBW
Light source Transmitted illumination: LED
Reflected illumination: LED
Average LED life span:10,000 hrs.
Input rating: AC 100-240V,

50/60Hz, 10W
Eyepieces MIC-EPA10x 10x / FN 22 / Diopter adjustment:-8D~+5D / Eyepiece

micrometer dist mountable
MIC-EPA15x 15x / FN 16 / Diopter adjustment:-8D~+5D / Eyepiece

micrometer dist mountable
MIC-EPA20x 20x / FN 12.5 / Diopter adjustment:-8D~+5D / Eyepiece

micrometer dist mountable
Dimensions / Weight Dimension (W*D*H):289.9 x 329.9 x 371.3 /

Weight: 5.2Kg
其他信息
microscope function

Compound
用户评价 (0)

评价

目前还没有评价

成为第一个“MIC-600 0.67-4.5X stereo microscope” 的评价者

您的电子邮箱地址不会被公开。 必填项已用 * 标注

Shipping & Delivery

EX-WORK price

ALL PRICE MIC TECH QUOTED IS EX-WORK PRICE.

OTHER PRICE INCLUDING SHIPPING WILL BE QUOTED UPON REQUEST.

FAS CPT CIP FCA FOB CFR CIF DPT DIP DDP

  • ALL TERMS OF SHIPPING IS NEGOTIABLE WITH MIC TECH
  • ALL SHIPPING METHODS IS JUST ON YOUR REQUEST
  • YOUR SATISFACTION IS OUR GOAL

相关产品

Close

MA2000 compound metallurgical microscope
