MIC-A20 biological microscope.
| MIC-A20 serials Biological microscope technical specification | |||||
| Technical specification | Model | ||||
| MIC-
A22 |
MIC-
A23 |
MIC-
A22i |
MIC-
A23i |
||
| Total magnification: 40X～1600X | |||||
| Viewing head | Binocular head, Interpupillary
distance 52-76mm, 30°inclined,360° rotatable, （47-76mm optional） |
● | ● | ||
| Trinocular head, Interpupillary
distance 52-76mm, 30°inclined,360° rotatable, （47-76mm optional） |
● | ● | |||
| Eyepiece | wile-field eyepiece :WF10X/18mm | ● | ●● | ●● | ●● |
| wild-field eyepiece :WF16X/15mm | ○ | ○ | ○ | ○ | |
| Nosepiece | revolving quadruple nosepiece | ● | ● | ● | ● |
| Objective | Achromatic objectives:4X,10X,40X,100X | ● | ● | ||
| Plan objectives:4X,10X,40X,100X | ○ | ○ | |||
| Infinite achromatic
objectives:4X,10X,40X,100X |
● | ● | |||
| Infinite plan objectives:4X,10X,40X,100X | ○ | ○ | |||
| Mechanical stage | 142x130mmdouble layer mechanical stage,
moving range76mm(X)x50mm（Y）with double section clamp |
● | ● | ● | ● |
| Focusing | Coaxial focus system with upper limited
and tension adjustment; coarse adjustment range:20mm, fine adjustment precision:0.002mm |
● | ● | ● | ● |
| Condenser | N.A.1.25 condenser | ● | ● | ● | ● |
| Illumination | 10 W LED illumination, brightness
adjustable or 6V/20W, 6V/30W halogen lamp |
● | ● | ● | ● |
| Filter | yellow, green, blue, neutral color filter | ○ | ○ | ○ | ○ |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
