MIC-C30 serials microscope
| Model | MIC-
C30M |
MIC-
C30B |
MIC-
C30T |
MIC-
C40B |
MIC-
C40T |
MIC-
C40IB |
MIC-
C40IT |
|
| Optical | Finite Optical System | ● | ● | ● | ● | ● | / | / |
| System | Infinite Optical System | / | / | / | / | / | ● | ● |
| Viewing
Head |
Monocular Head, Inclined at 30º ,
360º Rotatable |
● | / | / | / | / | / | / |
| Seidentopf Binocular Viewing Head,
Inclined at 30º ,360º Rotatable |
/ | ● | / | / | / | ● | / | |
| Seidentopf Trinocular Head,
Inclined at 30º ,360º Rotatable |
/ | / | ● | / | / | / | ● | |
| Eyepiece | Wide Field Eyepiece WF10X/18mm | ● | ● | ● | ● | ● | ● | ● |
| Wide Field Eyepiece WF16X/13mm | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
| Wide Field Eyepiece WF20X/11mm | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
| Objective | Finite 195 Achromatic Objectives
4X 10X 40Xs 100Xs(oil) |
● | ● | ● | ● | ● | / | / |
| Finite Plan Achromatic CF Objectives
4X 10X 40Xs 100Xs(oil) |
○ | ○ | ○ | ○ | ○ | / | / | |
| Infinite plan Objectives
4X 10X 40Xs 100Xs(oil) |
/ | / | / | / | / | ● | ● | |
| Nosepiece | Quadruple Nosepiece | ● | ● | ● | ● | ● | ● | ● |
| Quintuple Nosepiece | / | / | / | ○ | ○ | ○ | ○ | |
| Condenser | Abbe Condenser NA1.25
with Diaphragm,Filter |
● | ● | ● | ● | ● | ● | ● |
| Focusing
System |
Coaxial Coarse and Fine Adjustment,
Fine Division 0.002mm, Coarse Stroke36mm |
● | ● | ● | ● | ● | ● | ● |
| Stage | Double Layer Mechanical
Stage 110x125mm |
● | ● | ● | / | / | / | / |
| Double Layer Mechanical
Stage 142x132mm , Moving Range75mmx50mm |
/ | / | / | ● | ● | ● | ● | |
| Illumination | 3W/LED Adjustment,
rechargeable battery |
● | ● | ● | / | / | ○ | ○ |
| 6V/20W Halogen Lamp,
Brightness Adjustment |
/ | / | / | ● | ● | ● | ● | |
