MIC-CD610-5ANeurosurgery ENT ear, nose, throat, brain surgery motorized focusing surgical operating microscope
Objective: 250mm
Eyepiece: 12.5x WF
Illumination: Halogen Lamp
Magnification: 3x~16x
Focusing: Motorized Foot Focusing
Assistant binocular tube:optional
| Model | MIC-CD-610-5A |
| Function | ENT |
| Surgical microscope | |
| Magnification | 1:6 manual continuous zoom ,total magnification 3x~16x |
| Focusing range | Motorized 50mm by foot switch |
| Binocular tube | high brightness 90°binocular tube |
| Eyepiece | 12.5x / 10x |
| Objective lens | F 300mm(175mm, 250mm, 350mm optional) |
| pupil distance | 55mm~75mm |
| Diopter adjustment | +6D ~ -6D |
| Field of view | Φ95mm~Φ16mm |
| Illumination | |
| System | Direct illumination |
| Light source | Halogen lamp |
| Light intensity adjustment | 10 steps 0-60000lux |
| Fiber optic illumination | Single fiber |
| Field of illumination | Φ70mm |
| Arm & Base | |
| Mount | Floor stand |
| Maximum arm extension |
1100mm |
| Height from objective to floor | 800mm |
| Base size | 680*680mm |
| Brake system | Four-wheel brake |
| Foot switch | Waterproof, 2 function steps |
| Others | |
| Weight | 107KG |
| Power socket | 220v(+10%/-15%) 50HZ/110V(+10%/-15%) 60HZ |
| Power consumption | 180VA |
| Safety class | class I |
| Accessories | |
| CCD Camera system | Beam splitter, CCD adapter, CCD, Display |
| Mobile phone Adapter | Compatible with all models |
| Integrated Video Adapter | SONY / CANON Camera |
| Assistant tube | 360 degree Rota table |
| Ambient conditions | |
| Use | +10°C to +40°C |
| 30% to 75% relative humidity | |
| 500 mbar to 1060 mbar atmospheric pressure | |
| Storage | –30°C to +70°C |
| 10% to 100% relative humidity | |
| 500 mbar to 1060 mbar atmospheric pressure | |
