MIC-CD6C ophthalmology microscope Orthopedics thoracic surgery Plastic surgery dental surgery Microscope

The MIC-CD6C is the only model of MIC-CD serials operation microscope which has a double assistant binocular system. It have perfect optics system and the biggest depth of field. It can be used in Neurosurgery, ophthalmology surgery, dentistry.

Specification:Double assistant’s binocular, new changing diaphragm give you perfect depth of field

Eyepieces:magnification 12.5x, pupil distance adjustable range 55mm~75mm, diopter adjustment range +5D ~ -5D. Focus of second object lens 180mm.

Binocular tube:30°~90°variable angle binocular tube, add new pupil distance adjustment

Magnification :6:1 zoom, motorized, magnification 4.5x~27x; field of view Φ45~Φ7.5mm

Coaxial assistant’s binocular tube:manual 3-step changer, total magnification 6.4x,10.8x,17.3x; field of view Φ31mm,Φ19mm,Φ12mm

Coaxial illumination:illumination diameter of light spot Φ50mm, illumination intensity 100000lux

Objectives:f 200mm (Alternative 75mm,250mm,300mm,350mm,400mm etc )

Focusing:motorized, range +/-25mm, speed 33s/whole distance

X-Y translator:move in X-Y direction motorised, range +/-25mm

Maximum length of arm:1200mm

Oblique illumination:illumination range 50mm,illumination intensity 30000lx

Stand:swing angle of the carrier arm 0 ~300°,height from objective to floor 800mm<H<1250mm

Foot switch :waterproof, 8 function steps

Weight:164kg
