- Universal solenoid valve control spare arm
- Solenoid valve horizontal balance equipment
- 1:7 stepless zoom main body
- 180°multi-angle adjustable binocular head
- Coaxial light path with multi-angle adjustable assistant lens
- Wide field of view 10X eyepiece
- Bi-Xenon lamp high brightness illumination systems
- Aspheric surface design for the illumination, light spot adjustable.
- F200-450mmfocus adjustable objectives
- 1080P60HD video recording system
A Stereo & Colorful View from Olympus SZX7 Optics and Comfort View Eye Pieces
Microscope | Item | specification |
Main lens | OLYMPUS® SZX7 auto zooming lens | |
Eyepiece | 10xΦ28mm super wide filed of view eyepiece, 12.5x (Optional) | |
Binocular head | 0°-180° adjustable binocular head | |
Interpupillary distance | 55mm – 75mm | |
Diopter | ±5D | |
Zoom ratio | 1:7 | |
Working distance | 250mm/300mm/400mm/500mm fixed focus | |
200mm – 450mm motor driven focus(max. 500mm) | ||
Microscope moving range | ±270° horizontal or front/back | |
Total magnification | 2.2x-14.5x(WD 250mm) | |
Focus model | 5 solenoid valve combined braking, Double handle operation | |
Lens balance | Solenoid valve balance locking device | |
Illumination system | Light | Bi-Xenon Aspheric lamp, stepless brightness adjustable. |
Power | 250W | |
Control system | Hand shank | Zoom change, focus, X-Y, illumination, solenoid valve control |
Foot panel (optional) | Zoom change, focus, X-Y, illumination | |
Assistant equipment | Bridge hand mirror, 90° assistant lens | |
Video system (optional) | 1080P60 HD recording system, 4K camera |
