MIC-L510 Digital Ultrasonic Flaw Detector
Main Function
With high-precise positioning, it meets requirements of close and distant detection;
Small blind near-field allows the detection of small diameter, thin-walled tube;
Automatic calibration: with one-button automatic calibration, convenient operation, automatically testing the “zero”, “K value”, “forward” of the probe and “speed of sound” of the materials;
Automatic display the location of flaw echo (depth d, level p, distance s, amplitude, equivalent dB, ф aperture value);
Free switch to three kinds of standards (depth d, level p, distance s);
Automatic gain, return envelope, peak memory function improves detection efficiency;φ value calculation: forging straight probe testing, identifying the highest wave of defects, automatic conversing ф aperture value and calculating the large flat;
100 independent testing channels (expandable), you can freely enter and store any industrial testing standard, do field detection without test block;
Freely store and playback 500 A-scan wave forms and data;
DAC and AVG are automatically formed, without restriction of sub-sampling points, and can be corrected and compensated.
13 built-in testing standards can be used;
You can freely enter any industrial standards;
The width and intensity of launch pulse are adjustable;
It can connect to the computer, realizing data management, and exporting inspection reports of Excel format with A4 paper ;
26 million colors ultra-bright display, adjustable brightness, suitable for both intense and low light working environment;
Battery with a good performance of safety and environment-friendly, can work for 10 hours.
Time records: track and store records of testing date, time;
With power outage protection, stored data will not be lost;
Testing parameters can be automatically tested or preset;
With digital suppression, no effects for the gain and linearity;
Gain Compensation: Correcting dB attenuation caused by surface roughness, surface curvature, distant-testing of thick piece and other factors;
Technical Specification
Model | MIC-L510 |
Operating Frequency | 0.4MHz~15MHz |
Scanning Range | 0-6000mm |
Vertical linearity error | ≤3% |
Horizontal linearity error | ≤0.1% |
Dynamic Range | ≥32dB |
Noise Level | <8% |
Velocity Range | 1000~11000(m/s) |
Testing Sensitivity | ≥62dB (Depth 200mm, Φ2 flat bottom hole) |
Gain Range | 0~110dB |
Standby Time | ≥ 10 hours of continuous work |
Temperature | (- 20 ~ 70) ℃ |
Humidity | (20 ~ 95)% RH |
Overall dimension | 238×155×46mm |
Weight | 1.2kg |
Standard Delivery | Main Unit, Straight probe, Angle probe, 9V Power adapter, BNC cables, Crates,
Instructions Manual, Certificate, Packing card, Warranty card |
Optional Accessories | PC software, Standard test block, Coupling agent |
