Specification & Objective
| Magnification | Working distance(mm) | Viewing field for object space(mm) | Equipment |
| 2× | 208 | 68 | ● |
| 4× | 98 | 34 | ● |
| 6× | 80 | 22.7 | ● |
| 8× | 58 | 17 | ○ |
| 10× | 46 | 13.6 | ○ |
| 15× | 50 | 9.1 | ○ |
| 6×（SL） | 115 | 22.7 | ○ |
“●” is standard equipment. “○”is optional equipment.
Height: 1800mm
Free Viewing Body, Strength Range: 850mm, easily observe large area objective.
Stable stand, free sliding, long vertical distance is 580mm with boost up and down.
Universal block with tension adjustment in bottom, it can free to move or fix so that to observe in a good position.
Optional LED Illumination
Application range
Electronics: PCB Setting, QC, Screening, Rework & Weld
Precision project & Plastic: QC, Micro-welding, Micro-machining In jecting & Moulding
Medical & Dentistry Equipment Manufacturing: Finish machining
Setting, Fine Dressing, Color Matching, Rework & Overhaul
Biological medicine: Sample-Making, dissecting, Dyeing, Microscopy
Public Security system
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
For MIC-S13 with basementBase dimension：400×300×20 mm (15.74×11.81×0.78 inch)
Stand arm height:500 mm (19.68 inch)
Moving range : 200 mm
Exterior LED lighting
