MIC-SM2355 LED ENT dental stomatology surgical operating microscope

MIC-SM2355 LED ENT dental stomatology surgical operating microscope

Magnification system

* 5-steps manual magnification changer

* five click stop positions y=0.4x,0.6x,1x,1.6x,2.5x

Tube

* 0-190 deg inclinable binocular tube, f=170mm, diopter adjustable ±7D，interpupillary distance 50mm～80mm

Eyepieces (Optional)

*12.5x, 10x, 16x and 20X wide field eyepieces and have integrated eyecups with step less adjustment.

Magnification Range

* e.g. with f=250mm lens and 12.5x eyepieces:

* Magnification/Field-of-view diameter: 3.4x, 5.4x, 8.5x, 13.5x, 21.2x

65mm, 42mm, 26mm, 16mm, 10mm

with selected components, the above magnification range can be shifted up or down.

Focusing

* Manual, fine focusing range 12mm

* 5 objective lenses for optional:

f=200mm (with fine focus), f=250mm (with fine focus), f=300mm, f=350mm, f=400mm

Illumination

* MIC LED Illumination, supplies bright, white and shadow-free light,>20,000 hours lifetime * Yellow and green integrated filter

* Field of view diameter: 50mm with f=250mm objective lens

Gross Weight

* microscope 80kg

* Floor stand 125kg

* Wall Mount 80kg

* Ceiling Mount 95kg

* Fixed ground Mount 75kg

* Tabletop Clip 45kg
