MIC-TY2 type photoelectron colposcope

Besides cell diagnosis outside, in the clinical setting also become important auxiliary means, widely used in the early stages of the uterine neck cancer and deformed epithelium diagnosis work. As the vaginal mirror can really found naked eye cannot see even in cell diagnosis good to omissions in disease and syndrome and its scope, make the diagnosis accuracy greatly improve for early treatment. The instrument in addition to the above purposes, but to uterine neck benign disease diagnosis and treatment of chronic erosion operation decision plays an important role. Colposcopy and cell diagnosis is indivisible, and use these two complementary methods to diagnosis, can maximum limit to improve the diagnostic accuracy. MIC-TY2 type photoelectron colposcopy combined with image system and improve the inspection accuracy, call expert database data can be convenient diagnosis and generate reports, form the medical record files, has a wealth of RCI evaluation index.

Technical parameters

1. Single binocular straight cylinder lens focal length: 160 mm, also optional 45 ° eye lens and optical hinge can flip 180 °
2. Eyepiece 12.5 x, wide Angle, with apparent mirror adjustment and limit device
3. Working distance big objective: F: 300 mm
4. Coarse adjustment range: 180 mm, trimming focal scope: 40 mm
5. Mesh distance regulating range: 50-75 mm

Diopter adjustment range: ± 5 d

7. With filter conversion device
8. Cold light source 15 v, 150 w, Art surface illumination > 30000 lx or 50 w xenon lamp lighting
9. Power supply voltage and frequency: 220 v plus or minus 10%, 50 hz ± 1 hz
10. Optional optical splitter, teach mirror and CCD camera interface, and can be connected vaginal mirror image acquisition and processing system, forming a multi-purpose optoelectronic colposcope.
