MIC-W USB3.0 16MP microscope camera

MIC-W USB3.0 16MP microscope camera

Feature

1、USB3.0 digital interface

2、Max resolution 4632*3488；

3、Can capture image area for partial image processing

4、Support SDK second development

ENQUIRY!
分类： , , , 标签： ,
描述
Sensor SONY ICX687AQA 16MP
Pixel size 3.69UM*3.69UM
resolution@frame rate 1940×1460@25 1080P can reach 30fps
Data output 16bit YUV422
Data format YUV422 YUYV
area image ROI
image process GAMMA,LUT,saturation,sharpness
Global shutter(us) 25fps:10-40000, 30fps: 10-33000,step:1 Auto/manual
Gain (dB) 0-36,step:0.1 Auto/manual
WB (dB) 0-12,step:0.1 Auto/manual
Gamma coefficient 0.5~4.00
data interface USB3.0
GPIO 8PIN,HIROSE HR25:PWR,1xOPI,1xOPO,BIOx2 IO support mapping;
Trigger external trigger/software trigger;
Power DC5V,<4.5W, GPIO/USB
Lens interface C
camera control Driver
Working temperature 0-50
其他信息
microscope function

Infinite, Compound, Dark filed, Polarizing, PH, fluorescent
