MIC-WS serials video display biological microscope
| Model Items Spec. and parameter | MIC-WS | |
| LCD screen 10.6 inches IPS
Resolution: 1366×768 |
● | |
| Optical system | Finite optical system
Infinite optical system optional |
● |
| Eyepiece | WF10X/ø18 | ●● |
| WF16X/ø10 | ○ | |
| WF10X/ø18(Pointer) | ○ | |
| WF10X/ø18 (Reticle) | ○ | |
|
Objectives |
Infinite Plan Achromatic Objective 4X/10X/40X/100X (oil) | ○ |
| Plan Achromatic Objective 10X/25X/40X/100X (oil) | ● | |
| Head | Seidentopf binocular trinocular head 30°inclined interpupillary distance 47-78mm | ● |
|
Focus system |
Quadruple Nose piece
Coaxial coarse and fine konb, fine division 0.002mm, moving range 25mm |
● |
| Stage | Mechanical stage: size: 140×140, moving range:75×50mm | ● |
| Condenser | Fixed Abbe N.A.1.25 | ● |
| Move out condenser | ○ | |
| Dark field condenser (dry, oil) | ○ | |
| Polarizing kits | Polarizer and analyzer | ○ |
| Phase contract device | PH lens
PH condenser and slides |
○ |
| Base | 3W/LED | ● |
| Digital specification | Photo resolution: 4592×3072 | ● |
| Camera pixel: 12MP | ● | |
| Video resolution: 1080p/60fps | ● | |
| Storage:SD Card | ● | |
| Support WIFI connection | ● | |
| Automatic exposure, exposure offset, automatic white balance, multiple measuring functions, video recording, local storage | ● | |
| SD card | SD card, WIFI SD card | ● |
| Power supply | DC12V | ● |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
