MIC-ZJ6ELC ENT operation microscope, dental surgical microscope, oral surgical microscope, dentistry surgical microscope nerve surgery microscope
Features:
- Primary mirror the optical the hinged surgery barrel, the biggest flip angle of 180 °
- With fine focusing the objective lens (adjustable range ≥ 20mm), optional 250mm apochromatic objective.
- Primary mirror with a damping adjustment system, so that the optical lens can be maintained at any location within the moving range.
- Optical microscope head can be placed on the upper part of the bearing arm, and not affect other surgery performed during surgery.
- With an orange and green color filter, can be adjusted through the front portion of the pusher bar of the optical fiber.
- Coaxial illumination system, in the front of the instrument with the adjustment switch, the brightness of the lighting can be adjusted continuously.
- Spring arm Optional lighting limit switch, when not carried to that disconnect, especially convenient for the dentist’s surgery requires.
Option:
Optional large objective lens, a beam splitter, single mesh Teach mirror, eyes Assistant mirror, built-in or external cameras and interfaces, screen, digital camera system and interface, and optional xenon lamp lighting, limit lighting, and new rack.
Technical parameters:
- A primary mirror with optical hinge binocular or so before and after any tune pour biggest flip angle of up to 180 °
- Five-speed drum zoom magnification: 3.4X, 5.1X, 8.3X, 13.5X, 20.5XF=170mm
- Field of view diameter: Φ66mm, Φ41mm, Φ26mm No-, Φ16.5mm, Φ10.4mm
- Eyepiece 12.5X/18B
- Large objective lens with fine-tuning of focus, focal length: 250mm (optional 200,300,350,400) Focus range 20mm
- Coaxial cold light source fiber optic lighting, maximum illumination ≥ 60000Lx continuous dimming halogen or xenon lighting
- Contains orange and green color filters
- Rack wishbone maximum extension length ≥ 1350mm,height 1750mm
- The rack vertical lift range ≥ 500mm
- With DSLR systems 23 inches display HDMI camera, adapter.
- 11. Power: 220V/50Hz or 110V/60Hz
