Technical Data Sheet
| eyepiece | high eye point wide field eyepiece WF10X/20mm, WF15X/15mm,
WF20X/10mm ( can be mounted micrometer |
| high eye point wide field eyepiece diopter adjustable WF10X/20mm,
WF15X/15mm, WF20X/10mm ( can be mounted micrometer ) |
|
| observation head | MIC-ZL6 binocular head. 60 ° inclined, 360 ° rotatable; 0.67X ~ 4.5X
continuous zoom lens . Long working distance 100mm. Interpupillary distance adjustment range 54-75mm; two eyepieces diopter can be adjusted to regulate the range of ± 5 |
| MIC-ZL6T Tinocular head. 60 °inclined, 360 ° rotatable; photographic
camera can be equipped with the interface ; 0.67X ~ 4.5X continuous zoom lens . Long working distance 100mm. Interpupillary distance adjustment range 54-75mm; two eyepieces diopter can be adjusted to regulate the range of ± 5 |
|
| auxiliary lens | 0.5X/165mm. 2X/30mm. |
| focus brackets | A1 focus frames, focusing hand wheel adjustable elastic , lifting range 50mm. |
| A3 industrial binding Focus Frame ( industry-specific ) | |
| base | B1 Column small flat base |
| other external sources | ring light / LED light / fiber optic lighting |
