| Item | P-I11 | Order No. | |
| Frame | One-piece construction from arm to base | ● | P-I11 |
| UCIS Infinity Independent Achromatic Optical Design | |||
| With digital camera joint on the left side | |||
| Co-axial coarse and fine focusing knob,precision:0.001mm | |||
| Wide voltage:100∽240V,47/63Hz | |||
| Frame | One-piece construction from arm to base,with flourescence excitation interface | P-I11 | |
| UCIS Infinity Independent Achromatic Optical Design | |||
| With digital camera joint on the left side | |||
| Co-axial coarse and fine focusing knob,precision:0.001mm | |||
| Wide voltage:100∽240V,47/63Hz | |||
| Seidentopf Observation Tube | Binocular Tube, Interpupillary distance 52-75mm,45°inclined,diopter adjustable. | ● | MS1 |
| Binocular Tube, Interpupillary distance 52-75mm,45°inclined,diopter adjustable. | ○ | MS1A | |
| Eyepiece | WF10X/20, High eye-point up to21mm. | ●● | E1020PC |
| WF10X/22, High eye-point up to21mm. | ○○ | E1022PA | |
| WF16X/14mm | ○○ | E1614WB | |
| WF10X/20(Pointer), High eye-point up to21mm. | ○ | E1020GC | |
| WF10X/22(Pointer), High eye-point up to21mm. | ○ | E1022GA | |
| Reticule eyepiece: CROSSWF10X/20，High eye-point up to21mm. | ● | E1020RC | |
| Reticule eyepiece: CROSSWF10X/22，High eye-point up to21mm. | ○ | E1022RA | |
| Centering Telescope | CTE | ● | CTE |
| Infinity Long Work-distance Plan Objectives | 4X/0.13 WD12.86 | ○ | WB-L4A |
| 10X/0.25 WD9.67 | ● | WB-L10A | |
| 20X/0.40 WD7.97 | ● | WB-L20A | |
| 40X/0.60 WD3.76 | ● | WB-L40A | |
| Infinity Plan Positive Phase-Contrast Objevtives | 10X/0.25 WD9.67 | ○ | WB-LPHp10A |
| 20X/0.40 WD7.97 | ● | WB-LPHp20A | |
| 40X/0.60 WD3.76 | ○ | WB-LPHp40A | |
| Infinity Plan Negative Phase-Contrast Objectives | 10X/0.25 WD9.67 | ○ | WB-LPHn10A |
| 20X/0.40 WD7.97 | ○ | WB-LPHn20A | |
| 40X/0.60 WD3.76 | ○ | WB-LPHn40A | |
| Transmitted light Illumination | 72mm Extreme long work distance condenser,NA0.3,with iris diaphragm, 6V30W halogen lamp house, filter jack, | ● | SGJ1 |
| Phase-contrast slide, makes it easy to change between 10X,20X,40X phase-contrast and brightfield observation. | ● | PCB-LPH | |
| 6V30W Osram halogen lamp | ● | BZ-0022C | |
| External power, wide voltage (100V / 240V) | ● | DYX1 | |
| Fuse tube: 250V/3.15A Φ5X20 | ●●● | BZ-0023 | |
| Blue filter（φ34） | ● | LA1-1000 | |
| Green filter（φ34） | ● | LU1-1000 | |
| Yellow filter（φ34） | ● | LH1-1000 | |
| Stage | Fixed stage: 240*260mm, low-position co-axial flexible adjusting handle,travel:135mm*85mm | ● | ZT1 |
| Slide Plate(φ118mm), replaceable | ● | ZT1-1000 | |
| Slide Plate(76X26mm、Φ60), replaceable | ● | 1D-0021 | |
| Mechanical stage: 350*208mm，X/Y travel: 50mmX50mm，low-positioned co-axial flexible adjusting handle. | ○ | ZT1A | |
| Revolving Nosepiece | Quintuple, Inward facing. | ● | ZQ580A |
| C-Mount | 1X | ○ | SX3 |
| 0.5X | ● | SX1 | |
| 0.25X(Fit 1/3′CCD) | ○ | SX5 | |
| Digital Camera Adapter | ○ | SD2 | |
| Digital Camera Joint | (Please advice your digital camera model in advance) | ○ | SDK |
| Reflected Flourescence Attachment | DC Hg Florecence Lamphouse 100W | DYX3 | |
| Mercury lamp 100W(Made in China) | BZ-0022H | ||
| Mercury lamp 100W(Osram) | BZ-0022i | ||
| Filter Turret | |||
| Iris aperture adjusting handle | DLSS1-0029 | ||
| DC Hg Power Source House 100W | DYX3 | ||
| Fuse tube: 250V/5A Φ5X20 | BZ-0023A | ||
| UV Excitaion Filter (I Grade) | YGMKI-UV | ||
| V Excitation Filter (I-Grade) | YGMKI-V | ||
| B Excitation Filter (I-Grade) | YGMKI-B | ||
| G Excitation Filter (I-Grade) | YGMKI-G | ||
| UV Excitaion Filter (C-Grade) | YGMKC-UV | ||
| V Excitation Filter (C-Grade) | YGMKC-V | ||
| B Excitation Filter (C-Grade) | YGMKC-B | ||
| G Excitation Filter (C-Grade) | YGMKC-G | ||
| Dust helmet | ● | BZ1-0014 | |
| Operation Manual | ● | BZ1-0036B | |
| Allen Screw Driver | φ2mm | ● | BZ2-0018 |
| φ2.5mm | ● | BZ1-0018 | |
| φ3mm | ● | BZ1-0018A | |
| Power Wire | CE Certified | ●● | BZ-0021 |
| Package | Inner: Foam,Plastic Bag; Outer: Carton |
● | |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
