| Objective Body | Galileo optical system,
Left and right parallel optical path, Non-coaxial image, Zoom range: 0.68-4.5X |
● | 101101 | |
| Tube | Head incline is adjustable from 0°-30°,
180° outside rotation and higher eye point to 80mm, Eyepiece locked ring |
● | 102201 | |
| Focusing System | Coaxial coarse and
fine focusing system, Coarse stroke 240mm, Fine division 0.002m |
Without illumination | ● | 109101 |
| With 6V/15W
halogen reflecting illumination |
○ | 109102 | ||
| Eyepiece
(Diopter Adjustable) |
WF10X/23mm | ●● | 10X | |
| WF10X/23mm (Reticule, X axis: 0.1mm/100 division) | ○ | 10X101 | ||
| WF10X/23mm (Reticule, X axis: 0.05mm/200 division) | ○ | 10X102 | ||
| WF10X/23mm (Grid, X axis: 0.1 X 0.1mm/100 division) | ○ | 10X103 | ||
| WF16X/14mm | ○ | 16X | ||
| WF20X/12mm | ○ | 20X | ||
| WF25X/9mm | ○ | 25X | ||
| WF30X/8mm | ○ | 30X | ||
| Objective | 0.3X achromatic objective (W.D=328.93mm) | ○ | 0.3X | |
| 0.5X achromatic objective (W.D=197.19mm) | ○ | 0.5X | ||
| 0.7X achromatic objective (W.D=148.00mm) | ○ | 0.7X | ||
| 1X achromatic objective (W.D=93.87mm) | ● | 1.0X | ||
| 1X plan achromatic objective (W.D=84.92mm) | ○ | 1.0XPL | ||
| 1.5X achromatic objective (W.D=46.69mm) | ○ | 1.5X | ||
| 2X achromatic objective (W.D=34.04mm) | ○ | 2.0X | ||
| 2.5X achromatic objective (W.D=22.53mm) | ○ | 2.5X | ||
| Image Output Unit | One side image output unit | ○ | TR | |
| Double sides image output unit | ○ | TRS | ||
| Coaxial Illumination | 1W/LED illumination unit | ○ | TZLED/1W | |
| Single soft optical fiber 5W/LED cold light unit,
Fiber length: 550mm, Light passed diameter: 8mm |
○ | TZLED/5W | ||
| Base | Standard base (without illumination) | ● | 108102 | |
| Transmitting illumination base,
output: 3W/LED adjustable clod lighting |
○ | TS106104 | ||
| C-mount | 0.35X C-mount | ○ | 0.35XC | |
| 0.5X C-mount | ○ | 0.5XC | ||
| 1X C-mount | ○ | 1XC | ||
| Adaptor for
Digital Camera |
○ | |||
| Optical Fiber Cold
Lighting Unit (5W/LED) |
Ring soft optical fiber cold lighting unit,
Fiber length: 550mm, Light passed diameter: 8mm |
○ | LGY-R/LED | |
| Double hard optical fibers cold lighting unit,
Fiber length: 550mm, Light passed diameter: 8mm |
○ | LGY-D/LED | ||
| Single soft/hard optical fiber cold lighting unit,
Fiber length: 550mm, Light passed diameter: 8mm |
○ | LGY-S/LED | ||
| Optical Fiber Cold
Lighting Unit (150W/Halogen) |
Ring soft optical fiber cold lighting unit,
Fiber length: 550mm, Light passed diameter: 8mm |
○ | LGY-R | |
| Double hard optical fibers cold lighting unit,
Fiber length: 550mm, Light passed diameter: 8mm |
○ | LGY-D | ||
| Single soft/hard optical fiber cold lighting unit,
Fiber length: 550mm, Light passed diameter: 8mm |
○ | LGY-S | ||
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
