XJP-6A Inverted Metallurgical Microscope

XJP-6A inverted metallurgical microscope  has wide field eyepieces and simple polarization observation device, the Kohler illuminator is used in the transmitted and reflected illuminating system, the whole field is clear and uniformity. It is suitable for inspecting, such as semiconductor silicon wafer, LCD floor plate, electrocircuit plate, solid powder and all kind of industry sample that translucent or opaque. It is the ideal instruments in research work in biology, metallography, mineralogy, precision engineering, electronics, etc.

Features

  1. Adopt infinity optical system and modularization function design.
  2. Long W.D bright or dark field plan objectives (no cover glass), the field of view is widely and clear.
  3. Wide-field plan eyepieces: field number Ф22mm.
  4. Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm.
ENQUIRY!
分类： , , 标签： , ,
描述

XJP-6A Standard Outfits

Order No. Item Standard Outfits
XJP-6 XJP-6A
Main Body ● ●
S09 Mechanical stage with a stroke of 75 by 50 and size of 180 by 155 ● ●
EP10 Plan eyepiece 10X-18 ●● ●●
EP12.5 Plan eyepiece 12.X-14 ●● ●●
EH5 Huygenian ocular 5X-20 ○○ ○○
EW10 Plan eyepiece 10X-20 ○○ ○○
Epr10b Plan reticle eyepiece 10X-14 ● ●
B-OAr4 Achromatic objective 4/0.10 ●
M-OAr10 Achromatic objective 10/0.25 ●
M-OSPr40 S-plan achromatic objective 40/0.65 ●
M-OAor100 Achromatic objective 100/1.25 oil ●
B-OPr2.5 Plan achromatic objective 2.5/0.07 ○ ○
B-OPr4 Plan achromatic objective 4/0.10 ○
M-OPr10 Plan achromatic objective 10/0.25 ●
M-OPr20 Plan achromatic objective 20/0.35 ○ ●
M-OPr40a Plan achromatic objective 40/0.65 ●
M-OSPor100 S-plan achromatic objective 100/1.25 oil ●
9J-6 Stage plate (1) ● ●
9J-7 Stage plate (2) ● ●
9J-8 Stage plate (3) ● ●
9J-9 Stage plate (4) ○ ○
9J.11 Stage plate holder ● ●
TBR03 Rotating binocular head (45 degree) ● ●
LH01 Lamp housing ● ●
Halogen lamp 6V30W ●● ●●
PO02 Polarizer ● ●
PA01 Analyzer ● ●
CL02 Specimen clamps ● ●
9J.7 Photo adaptor ○ ○
EPHp5 Photo eyepiece S5x ○ ○
EPHp6.3 Photo eyepiece S6.3X ○ ○
EPHp0.65 Video eyepiece 0.65X ○ ○
Metallurgical Microphotography equipments ○ ○
35mm DF camera with shutter release ○ ○
SC03 Specimen holder ○ ○

Note: “●” in the table is standard attachment. “○” is optional accessories.

Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.

其他信息
microscope function

finite, Inverted, Polarizing
