| Parts | Specification | XSF-9 | XSF-9PH |
| Main Body | Including left & right hand plate,
four M4 screws, one screwdriver |
● | ● |
| Total Magnification | 100X-400X | ● | / |
| 40X-640X | ● | ||
| Eyepiece | Wide field ?WF10x/20 | ● | ● |
| Wide field WF10x/18,
with micrometer 0.1mm |
/ | ● | |
| Wide field ?WF16x/13mm | / | ● | |
| Viewing Tube | Compensation binocular head,
45° inclined, interpupillary distance 50-75mm |
/ | / |
| Compensation trinocular head,
45° inclined, interpupillary distance 50-75mm |
● | ● | |
| Nosepiece | 4 Holes revolving nosepiece | ● | ● |
| Long working
Distance Plan objective |
LPL2.5X/0.07，W.D.=29.7mm | / | / |
| LPL4X/0.10，W.D.=17.5mm | / | ● | |
| LPL10X/0.25，W.D.=7.9mm | ● | ||
| LPL25X/0.40，W.D.=5.0mm | ● | ● | |
| LPL40X/0.65，W.D.=3.0mm | ● | ● | |
| Long working
distance Plan phase contrast objective |
LPL Ph+ 10X/0.25，W.D.=7.9mm | ● | |
| LPL Ph+ 25X/0.40，W.D.=5.0mm | ● | ● | |
| LPL Ph+ 40X/0.65，W.D.=3.0mm | ● | ||
| Focusing System | Coaxial coarse & fine focusing knob,
with rack stop, coarse focusing range 22mm, fine focusing graduation 0.002mm |
● | ● |
| Stage | Fixed stage, with specimen clip,
size 170x195mm |
● | / |
| Mechanical stage, size 170x195mm,
moving range 71x78mm, minimum scale 0.1mm, with specimen plate, culture dish plate. |
/ | ● | |
| Phase contrast
slide 25x |
Including 25x phase contrast slide,
and one bright field hole. |
● | ● |
| Phase contrast
slide 10x， 40x |
Including 10x, 40x phase contrast slide,
and one bright field hole. |
/ | ● |
| Condenser | N.A.=0.35，W.D.=45-102mm | ● | ● |
| Filter | Blue and green 1 pc for each color | ● | ● |
| Light Source | Tungsten halogen lamp, 6V20W,
brightness adjustable, G4 lamp holder is made in China |
● | / |
| Tungsten halogen lamp, 6V20W,
brightness adjustable, imported G4 lamp holder |
/ | ● | |
| Power | Switch power, 100V-250V wide voltage | ● | ● |
| Power Plug | 220V/50Hz, National Standard | ● | ● |
| Can supply according to customer | / | / | |
| Packing | Foam plastic + carton | ● | ● |
| Video Adapter | 1X Video Adapter | / | ● |
| Optional
Accessories |
Stage micrometer 0.01mm | / | / |
| Photo tube 0.6x, 1x | / | / | |
| 1/3’CCD mount, 1/2’CCD mount | / | / | |
| Digital camera adapter, Digital SLR camera adapter |
/ | / | |
| CCD camera, digital camera,
digital video camera |
/ | / |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
