| Total Magnification: 4×-2000× | XSP
-125 |
XSP
-126 |
|
| Finite optical system | ● | / | |
| Infinite optical system | / | ● | |
| Viewing Head | Siedentopf binocular viewing head, inclined at 30°,
360°rotatable, interpupillary distance 47-75mm |
● | ● |
| Siedentopf trinocular viewing head, inclined at 30°,
360°rotatable,interpupillary distance 47-75mm with digital viewing head 5MP support WIFI |
○ | ○ | |
| Digital 8 inches LCD screen, inclined at 30°,360°rotatable,
interpupillary distance 47-75mm 5MP Android OS |
○ | ○ | |
| Eyepiece | Eyepiece WF10×18mm | ● | / |
| Wide field eyepiece WF10×/20 mm | / | ● | |
| Wide field eyepiece 12.5×14mm | ○ | / | |
| Wide field eyepiece 15×16mm | / | ○ | |
| Wide field eyepiece 16×12mm | ○ | / | |
| Wide field eyepiece 20×12mm | / | ○ | |
| Objective | Finite achromatic objective 4X, 10X,40X,100X | ● | / |
| Infinite Semi plan achromatic objective 20X, 60X | / | ● | |
| Nosepiece | Backward quadruple nosepiece | ● | ● |
| Backward quintuple nosepiece | ○ | ○ | |
| Focusing | Coaxial coarse & fine adjustment, fine division 0.002mm,
fine stroke 0.2mm per rotation, moving range 25mm |
● | ● |
| Stage | Double layer mechanical stage 140×140mm, cross travel
70×50mm, using low-positioned X/ Y coaxial control knob |
● | / |
| Double layer rackless mechanical stage 156×139mm, cross travel
75×52mm, using low-positioned X/ Y coaxial control knob |
/ | ● | |
| Condenser | Abbe condenser NA1.25 with aperture diaphragm | ● | ● |
| Dark field condenser (dry, oil) | ○ | ○ | |
| Illumination | S- LED light, brightness adjustable | ● | ● |
| 5W LED light, brightness adjustable | ○ | ○ | |
| 6V20W halogen lamp | ○ | ○ | |
| Battery rechargeable | ○ | ○ | |
| Kohler illumination | ○ | ○ | |
| ECO function | ○ | ○ | |
| Plane concave mirror | ○ | ○ | |
| Video attachment | ○ | ○ | |
Optional:
Photo attachment, Video attachment, Polarization set,Phase contrast kit,Epi-Fluorescent attachment
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
