XSP-C biological microscope
Back to products
Next product
XSJ-2 biological microscope

XSP-136 biological microscope

This series microscope is developed for various applied scopes. From daily work to scientific research, it is widely used in Biology, Histology, Pathology, Medicament chemistry research and Clinical examination. It is also used for education  Colleges and Schools.

ENQUIRY!
分类： , , 标签： ,
描述
Specification Model
XSZ-136A XSZ-136B XSZ-136E
Viewing Head Monocular Inclined at45°,360°Rotatable ●
Compensation Free Binocular Head,Inclined at

30°(55mm-75mm)

 ●
Compensation Free Trinocular Head,Inclined at

30°(55mm-75mm)

 ●
Eyepiece WF10×/18mm ● ● ●
Objective Achromatic 4×、10×、40×(s)、100×(s)oil ● ● ●
Stage Double layers mechanical stage ● ● ●
Stage size:135mm×135mm
Moving Range:70mm×30mm
Condenser N.A.1.25Abbe Condenser with iris diaphragm

and filter

 ● ● ●
Focusing Coaxial coarse & fine focusing adjustment

Fine focusing scale value 0.002mm

 ● ● ●
Light Source Halogen bulb 6V/20W,AC 220V/110V ● ● ●
OptinalAccessory Eyepiece:WF16×、WF20×

Objective:20×、60×(s)

Compensation Free Binocular & Trinocular Head(48mm-75mm)

LED illumination







Specification Model
XSP-136F XSP-136H XSP-136T
Viewing head Monocular Head.Inclined at 45 ° ●
Compensation Free Binocular Head. Inclined at  3 0 ° ( 55mm -75mm ) ●
Compensation Free Trinocular Head. Inclined at  3 0 ° ( 55mm -75mm ) ●
Eyepiece WF10 × ● ● ●
Objective Achromatic objective: 4X ,10X ,40X (S),100X (S)Oil ● ● ●
Stage Double layers mechanical stage ● ● ●
Stage size: 140mm × 140mm ● ● ●
Moving range: 75mm × 50mm ● ● ●
Condenser N.A1.25 Abbe condenser with iris diaphragm &  filter ● ● ●
Focusing Coaxial coarse & fine focusing adjustment with  rack and pinion mechanism Fine focusing scale Value 0.002mm ● ● ●
Collector High brightness collector and can be  interconverted with Kohler illumination ● ● ●
Light source Halogen tungsten bulb 6V/30W.AC 85V-230V ● ● ●
Adjustable brightness
Optional Accessory Eyepieces: WF16x,WF20x,P16x 1.3 Mega pixels CMOS electronic eyepiece .
Semi-plan   objectives: 4X,10X,20X(S),40(S),60X(S),100(S)Oil Photo and CDD attachment
其他信息
microscope function

Infinite, Compound, Dark filed, Polarizing, PH, fluorescent
