| Specification | XSZ-158 | |
| Viewing head | Compensation Free Binocular Head,
Inclined adjustment 0 ° -40 ° |
● |
| Compensation Free Trinocular Head ,
Inclined adjustment 0 ° -40 ° |
○ | |
| Interpupillary
Distance |
55mm -75mm | ● |
| Eyepiece | WF10X/ 22mm | ● |
| WF16X,WF20X,WF25X,P16X | ○ | |
| Nosepiece | Quintuple nosepiece | ● |
| Sextuple nosepiece | ○ | |
| Objective | Infinity plan objectives:4X,10X,40X(S),100X(S) Oil | ● |
| Infinity plan objectives:20X(S),60X(S) | ○ | |
| Stage | Double layers mechanical stage | ● |
| Stage size:180mmX 160mm | ||
| Moving range :75mmX 50mm | ||
| Condenser | Swing type N. A.1.25 Abbe condenser with iris diaphragm&filter | ● |
| Focusing | Coaxial coarse&fine focusing adjustment with rack
and pinion mechanism Fine focusing scale Value 0.002mm |
● |
| Collector | Kohler illumination | ● |
| Light
source |
Halogen bulb12V/30W 12V/50W or 12V/100W.AC85-230V |
● |
| Adjustable brightness | ||
| Optional
Accessory |
Fluorescent attachment | ○ |
| Phase contrast attachment | ○ | |
| Dry&Immersion dark field condenser | ○ | |
| Simple polarization attachment | ○ | |
| 3.0or1.3Mega pixel, CMOS electronic eyepiece | ○ | |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
