Specification | Model | ||
XSZ-166 | XSZ-166T | ||
Viewing head | Compensation free binocular head,inclined at 30°(48mm-75mm) | ● | |
Compensation free binocular head,inclined at 30°(48mm-75mm) | ● | ||
Eyepiece | WF10×/22mm | ● | ● |
Objective | infinite Semi-Plan objective:4×,10×,40×(s),100×ion(s)Oil | ● | ● |
Stage | Double layers mechanical stage
Stage Size:180mm×160mm Moving Range:75mm×50mm |
● | ● |
Double Mechanical Stage: super big 216x150mmplatform,
with X/Y travel of 75x55mmby low-Positioned X/Y coaxial control knob, with scale mark and specimen-slide clip, enough space to hold 2 specimen-slide. |
|||
Nosepiece | quadruple, inward facing. | ● | ● |
quintuple, inward facing | |||
sextuple inward facing | |||
Condenser | N.A.1.25Abbe condenser with iris diaphragm & filter holder | ● | ● |
Focusing | Coaxial coarse & fine focusing adjustment with rack and
pinion mechanism , fine focusing scale value0.002mm |
● | ● |
Light Source | Halogen bulb 12V30W. AC85V-230V Adjustable brightness | ● | ● |
Collector | High brightness Kohler illumination | ● | ● |
Optional Accessory:
Eyepiece:WF16×,WF20×,P16×
and 3.0Mega CMOS Digital camera eyepiece
infinite Semi-Plan objective:20×(s), 60×(s),
infinite Plan Objective:4×,10×, 20×, 40×(s), 60×(s), 100×(s)Oil
Light Source:LED,Adjustable brightness
Phase contrast attachment
Photography attachment and CCD C-mount:0.5X,0.57X,0.75X,1X
1.3Mega,2.0Mega,3.0Mega, 5.0Mega,10.0Mega
pixels CMOS Digital camera eyepiece
CCD Camera,color 1/3 High resolution 700 TV lines
