    BS serials biological Microscope

    Specification:

    1. Ergonomicdesign, finite or infiniteOptical System
    2. WF10x18 Plan Eyepieces
    3. 48-75mm Interpupillary Distance Settings, ±5 Diopter Adjustment
    4. Quadruple Nosepiece Inward Facing with Positive Click Stops
    5. Plan Achromatic 4x, 10x, 40x(S) and 100x (S/Oil) Objectives
    6. Right Hand Controls, Low Position, Mechanical Stage,Mechanical Stage, Size:156mmX138mm, Range: 76x54mm
    7. Coaxial Coarse and Fine Focus Mechanism with Markings on Knobs. Fine Focus Sensitivity 0.001mm
    8. 6v 20w Halogen or 3W LED Illumination, 110-240V Wide Voltage
    9. Dust Cover, Clear Blue Filter, Power Cord, Immersion Oil
    ENQUIRY!
    分类： , , 标签： , , ,
    描述
    Model

    Items Spec. and parameter

    		 BS100 BS101 BS201 BS202 BS203 Order No.
    Eyepieces WF10X/ø18 ● ● ●● ●● ●● EP10f
    WF16X/ø10 ○ ○ ○○ ○○ ○○ EP16c
    WF10X/ø 18 (pointer) ○ ○ ○ ○ ○ Epg10a


    Achromatic Objectives

    		 Achromatic Objective 4X/0.10 ● ● ● ○ ○ B-OA4d
    Achromatic Objective 10X/0.25 ● ● ● ○ ○ B-OA10e
    Achromatic Objective (S) 40X/0.65 ● ● ● ○ ○ B-OA40e
    Achromatic Objective (S) 100X/1.25(oil) ● ● ● ○ ○ B-OAo100d


    Plan Achromatic

    Objectives

    		 Plan Achromatic Objectives 4X/0.10 ○ ○ ○ ● ● B-OSP4a
    Plan Achromatic Objectives 10X/0.25 ○ ○ ○ ● ● B-OSP10b
    Plan Achromatic Objectives (S) 40X/0.65 ○ ○ ○ ● ● B-OSP40f
    Plan Achromatic Objectives (S) 100X/1.25(oil) ○ ○ ○ ● ● B-OSPo100b
    Head Monocular Head: Inclined 45° Rotatable 360°,

    Interpupilary Distance: 53-75mm

    		 ● ● TM20
    Sliding Binocular Head: Inclined 45°,

    Rotatable 360°, Interpupilary Distance: 52-75mm

    		 ● ● TB12
    Seidentopf binocular head, Inclined 30°,

    Rotatable 360°, Interpupilary Distance: 52-75mm

    		 ● TBR17
    Main Body Quadruple Nose piece, Coaxial Coarse and

    Fine Focusing Knobs Natural Light

    		 ● A14a
    Quadruple Nose piece, Coaxial Coarse and

    Fine Focusing Knobs

    		 ● ● ● A14
    Quadruple Nose piece, Coaxial Coarse and

    Fine Focusing Knobs Auxiliary Lens Built-in Body

    		 ● A14b
    Stage Mechanical stage: size: 135×130, moving

    range:75×50

    		 ● ● ● ● ● S31a
    Condenser Abbe N.A.1.25 ● ● ● ● ● C27
    Mirror Inserted ○ ○ ○ ○ MT07
    Fixed ● MT07a
    Collector ● ● ● ● ● COL03
    Base Halogen Tungsten Lamp: 6V/20W, wide voltage input ● ● ● ●  B32
    LED: 0.5W, wide voltage input ○ ○ ○ ○ B32b
    LED (chargeable): 0.5W, wide voltage input ○ ○ ○ ○  B32c



    Model

    Items Spec. and parameter

    		 BS203i BS203dn BS203dw BS204 Order No.
    Eyepieces WF10X/ø18 ●● ●● ●● ●● EP10f
    WF16X/ø10 ○○ ○○ ○○ ○○ EP16c
    WF10X/ø 18 (pointer) ○ ○ Epg10a


    Achromatic Objectives

    		 Achromatic Objective 4X/0.10 ○ ○ ● B-OA4d
    Achromatic Objective 10X/0.25 ○ ○ ● B-OA10e
    Achromatic Objective (S) 40X/0.65 ○ ○ ● B-OA40e
    Achromatic Objective (S) 100X/1.25(oil) ○ ○ ● B-OAo100d


    Plan Achromatic

    Objectives

    		 Plan Achromatic Objectives 4X/0.10 ○ ○ ● B-OSP4a
    Plan Achromatic Objectives 10X/0.25 ○ ○ ● B-OSP10b
    Plan Achromatic Objectives (S) 40X/0.65 ○ ○ ● B-OSP40f
    Plan Achromatic Objectives (S) 100X/1.25(oil) ○ ○ ● B-OSPo100b
    Infinite Achromatic Objectives Infinite Achromatic Objectives 4X/0.10 ● B-OAi4a
    Infinite Achromatic Objectives 10X/0.25 ● B-OAi10a
    Infinite Achromatic Objectives (S) 40X/0.65 ● B-OAi40a
    Infinite Achromatic Objectives (S) 100X/1.25(oil) ● B-OAi100a
    Head Seidentopf binocular head, Inclined 30°, Rotatable 360°, Interpupilary Distance: 52-75mm ● TBR17
    Seidentopf binocular head, Inclined 30°, Rotatable 360°, Interpupilary Distance: 52-75mm (Infinite) ● TBR20
    Seidentopf trinocular head, Inclined 30°, Rotatable 360°, Interpupilary Distance: 52-75mm ○ TTR20
    Seidentopf trinocular head with external digital video device ● TTR09b
    Seidentopf trinocular head with build in digital video device ● TTR09c
    Stage Mechanical stage: size: 135×130, moving range:75×50 ● ● ● ● S31a
    Condenser Abbe N.A.1.25 ● ● ● ● C27
    Collector ● ● ● ● COL03
    Base Halogen Tungsten Lamp: 6V/20W, wide voltage input ● ● ● ●  B32
    LED: 0.5W, wide voltage input ○ ○ ○ ○ B32b
    LED (chargeable): 0.5W, wide voltage input ○ ○ ○ ○  B32c

    Note: “●” in the table is standard attachment. “○” is optional accessories.

    Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
