MIC-4K UHD 8MP HDMI microscope camera

MIC-4K UHD 8MP HDMI microscope camera with SD card

4k High Definition industrial camera High Performance、Low Price

Introduction

With the increasing popularity of 4k monitor in china,the standard of HDMI 1080 pixel images appear more conservation and HDMI 1080 pixel images can not use the sharpness of monitor effectively.combined with the latest high-definition high-speed CMOS image sensors,FPGA hardware image processing and HDMI V1.4 version of the interface specification,our company recently released two high-definition industrial cameras—–MIC-4K and MIC-4KS

MIC-4K use the industry’s highest sensitivity, 2/3inch,pixel size of 2.5um, 800-megapixel color CMOS image sensor;MIC-4K use the 1/1.9inch,pixel size of 1.86um, 800-megapixel color CMOS image sensor.Both output 4k image resolution of 3840 × 2160 pixels,equivalent to four times the 1080 pixels camera image resolution,with a high dynamic range, high sensitivity and excellent thermal noise suppression.uncompressed image display speed up to 30 frames /sec,bandwidth to a staggering 5.97Gb/sec.the camera can display every details in the HDMI output ,your can connect HDMI frame grabber and it supports Plug &Play.BMP images can be captured in real time to the camera TF card,maximum support 64 Gb storage.

The camera is equipped with IR remote control ,you can adjust the parameter settings for fast,support hardware white balance,auto exposure ,the default 2800k,5000k,6500k color correction, two crosses,image flip, freeze, capture image playback, the shutdown parameters to save and many other functions. future upgrade versions will support multiple measurement functions.

Parameter list
