MIC-A1 upright metallurgical microscope

Be suitable in the field of electronics, metallurgy, chemicals and instrument industry. If could visualize the transparent, semitransparent or opaque material.

Plan achromatic optics and Epi Kohler illumination system and anti-reflective structure in the epi-illumination system, can make the image clarity better contrast of field of view. And effectively prevent interference by stray light.

■ The stable and reliable operating mechanism provide clearer image and easier to operate.

■ Modulate microscope body with a new ergonomic design, structural symmetry, can used with many kinds of accessories.

■ Stage, light intensity and low position coarse and fine adjustment, increased comfort of operating.

■ Widely used in various types of semi-conductor silicon wafer inspection, materials science study, geology mineral analysis and precision engineering and other disciplines

ENQUIRY!
分类： , , 标签： , ,
描述
Technical Specification Model
MIC-A102 MIC-A103 MIC-A108 MIC-A109
Viewing

Body

 Monocular Body Square 45°Incline ●
Dual Viewing body ●
Binocular Body 30°Incline, Interpupillary

Adjustable Distance:

55mm～75mm

 ●
Trinocular Body ●
Eyepiece WF10×(Viewing Field Diameter:ø18mm)
WF16×(Viewing Field Diameter:ø11mm)		 ● ● ● ●
Metallurgical Plain-field Objectives (without cover glass)

4×NA0.1, 10×/NA0.25, 40(S)×/NA0.65

 ● 　● 　● 　●
Mechanical

Stage

 Size:130mm×122mm

Moving Range:70mm×30mm Vernier Division:0.1mm

 ● ● ● ●
Nosepiece Nosepiece of Three Holes Revolving On Ball ● ● ● ●
Focusing Coaxial Coarse And Fine Focusing System ● ● ● ●
Focusing Range: 40 mm
Division Of Fine Focus Adjustment:0.002mm
Upright

Vertical

Illumination

 110V, 220V/6V 20W Halogen Bulb,

with brightness adjustable;

Filter(Light Blue、Light Green)

 ● ● ● ●
Optional

Accessory

 Photo Unit
Color Micro-TV Unit
Digital Micro-Photo Unit
Metallurgical Achromatic Objectives: 63X(s)、100X(s、oil)
Plain-Field Eyepiece: 12.5×/ø11、20×/ø11
Optional Transmit light source 6V 20W
其他信息
microscope function

finite, Compound, Polarizing
