MIC-PAD550 5MP 9.7 inches

MIC-PAD550 5MP 9.7 inches WIFI

9.7inch PAD Android Digital Microscope Camera, Screen Definition 1024*768 C mount, High Resolution 5MP 1/2.5inch cmos Sensor Support WIFI output, HDMI output, Mouse input and SD card Free software to take photo, record video and measurement

Introduction

The MIC-PAD550 is the third generation smart digital microscopic camera, which inherits the perfect integration concept of MIC-PAD500 on the functions of digital imaging, storage, processing and transmitting. Equipped with the most stable hardware and software system, binding professional multi-functional measurement software, which is R&D by ourselves. it is easy to achieve all your desires of exploration and discover the mystery of the microscopic kingdom. Very Important, Compare to other model PAD camera, this model is quite cheap and performance also very good. So we think this model can be well accepted by customers and will be widely used all over the world,

ENQUIRY!
分类： , , 标签： , , , , ,
描述

Specification:

Specification Model MIC PAD550
Series Integrated display camera
Sensor size 1/2.5″
Effective pixel 5 million pixels
Resolution 2048*1536@15FPS
Screen Resolution 2048*1536 Retinal Screen
Output USB2.0, HDMI, TF card, WIFI
Pixel size 2.2*2.2μm
Power DC-12V/2A
Features UI Easy mouse control, , Android5.1 operation system
Mark function Point coordinates, Reticle, Coordinates, Text annotation
Length measurement Straight length, broken line length, curve line length, distance between parallel lines,point-line distance
Center distance of circles Center distance of circles
Geometry measurement Line length, radius setting circle, two points setting circle, three points setting circle, concentric circles
Geometry area Polygon,Square
Image capture Support 16 million static image capture
Video record Supports 1080P video
Measurement tool MIC TECH-S-EYE
Package Size 238.00*51.00*206.00mm
Weight 0.6kg
Accessory DC-12V Power adapter
其他信息
microscope function

Infinite, Compound, Dark filed, Polarizing, PH, fluorescent
