Standard Configuration
| Model | XSL-16A | XSL-16B |
| Eyepiece | Wide field WF10X(¦µ18mm) | |
| Objective | Achromatic 4X/0.10 | Semi-plan achromatic 4X/0.10 |
| Achromatic 10X/0.25 | Semi-plan achromatic 10X/0.25 | |
| Achromatic 40X/0.65(Spring) | Semi-plan achromatic 40X/0.65(Spring) | |
| Achromatic 100X/1.25(Spring, oil) | Semi-plan achromatic 100X/1.25(Spring, oil) | |
| Eyepiece tube | Binocular(Inclination of 30˚) | |
| Focus system
|
Coaxial coarse/fine focus, with tensional adjustable and up
stop minimum division of fine focusing: 2μm. |
|
| Nosepiece | Quadruple(Frontward ball bearing inner locating) | |
| Stage | Double-layer mechanical (Size:135mmX125mm,
Move range: 75mmX35mm) |
|
| Abbe condenser | N.A.1.25 Rack & pinion adjustable | |
| Filter | Blue filter | |
| Frosted filter | ||
| Collector | For halogen lamp | |
| Light source | 6V 20W Halogen lamp with brightness control | |
Optional accessories
| Name | Sort/Technique parameter | ||
| Eyepiece | Wide field WF16X(11mm) | ||
| Dividing 10X(18mm) 0.1mm/Div | |||
| Objective | Plan achromatic 4X/0.10 | ||
| Plan achromatic 5X/0.12 | |||
| Plan achromatic 10X/0.25 | |||
| Plan achromatic 20X/0.40 | |||
| Plan achromatic 40X/0.65(Spring) | |||
| Plan achromatic 60X/0.85(Spring) | |||
| Plan achromatic 100X/1.25(Spring, oil) | |||
| Eyepiece tube | Monocular ( Inclination of 30˚) | ||
| Binocular, Sliding(Inclination of 45˚) | |||
| Trinocular, Sliding(Inclination of 45˚) | |||
| Trinocular( Inclination of 30˚) | |||
| Dual viewing tube (Inclination of 30˚) | |||
| Nosepiece | Quintuple (Frontward ball bearing inner locating) | ||
| Filter | Green filter | ||
| Yellow filter | |||
| Light source | LED
Collector |
Bright and white light | |
| Condenser | Dark field | Dry | |
| Immersion | |||
| Phase
contrast unit |
Eyepiece | Centering telescope | |
| Objectives | Phase contrast plan achromatic 10X/0.25 PHP | ||
| Phase contrast plan achromatic 20X/0.40 PHP | |||
| Phase contrast plan achromatic 40X/0.65 PHP(Spring) | |||
| Phase contrast plan achromatic 100X/1.25 PHP(Spring, oil) | |||
| (PHP) Turnplate phase contrast condenser | |||
| (PHP) Turnplate phase contrast condenser | |||
| Flashboard phase contrast condenser | |||
| Pull board phase contrast condenser | |||
| Infinity
optical system |
Eyepiece
tube |
Binocular (Inclination of 30˚) | |
| Trinocular( Inclination of 30˚) | |||
| Eyepiece | Centering telescope | ||
| Objectives | Infinity plan achromatic 4X/0.10 | ||
| Infinity plan achromatic 10X/0.25 | |||
| Infinity plan achromatic 20X/0.40 | |||
| Infinity plan achromatic 40X/0.65(Spring) | |||
| Infinity plan achromatic 100X/1.25(Spring, oil) | |||
| Infinity phase contrast plan achromatic 10X/0.25 PHP | |||
| Infinity phase contrast plan achromatic 20X/0.40 PHP | |||
| Infinity phase contrast plan achromatic 40X/0.65 PHP(Spring) | |||
| Infinity phase contrast plan achromatic 100X/1.25 PHP(Spring, Oil) | |||
| CCD adapter | 0.4X | ||
| 0.5X | |||
| 1X | |||
| 0.5X with dividing 0.1mm/Div | |||
| Camera | DV-1(With USB & video output) | ||
| DV-2(With USB output) | |||
| DV-3(With video output) | |||
| Photography | USB Output | ||
| VIDEO Output | |||
| Digital camera adapter
CANON Digital camera adapter(A610,A620,A630,A640) |
|||
| Photograph unit | 2.5X/4X Change over photograph attachment with 10X viewing eyepiece | ||
| 4X Focusing photograph attachment | |||
| MD Adapter | |||
| PK Adapter | |||
| Facility polarize | Polarizer(360° rotatable stage) | ||
| Analyzer | |||
| Adapter
(For LED illumination) |
Input: 230V50/60HZ Output: 9V 500mA | ||
| Input: 110V50/60HZ Output: 9V 500mA | |||
