| XSP-100 | ||
| Viewing
Head |
Seidentopf Binocular Viewing Head, Inclined at
30°, 360° Rotatable, Interpupillary 48-75mm |
● |
| Seidentopf Trinocular Viewing Head, Inclined at
30°, 360° Rotatable, Interpupillary 48-75mm |
○ | |
| Eyepiece | WF10×/18 | ● |
| WF16×/12 | ○ | |
| Objective | Achromatic Objective 4×, 10×, 40×, 100× | ● |
| Plan Achromatic Objective 4×, 10×, 40×, 100× | ○ | |
| Infinite Plan Achromatic Objective 4×, 10×, 40×, 100× | ○ | |
| Nosepiece | Quadruple Nosepiece | ● |
| Focusing
System |
Coaxial Coarse and Fine Adjustment, Fine
Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 20mm |
● |
| Stage | Double Layers Mechanical
Stage132×142mm/75×40mm |
● |
| Condenser | Abbe Condenser NA1.25 with Aperture Diaphragm | ● |
| Illumination | 3W LED | ● |
| 12V/20W Halogen Lamp, Brightness Adjustable | ○ | |
| Kohler Illumination | ○ | |
| Optional | Photo Attachment, Video Attachment,
Dark Field Condenser |
○ |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
