XTX-3 step zoom stereo microscope
Back to products
Next product
XTX-5 step zoom stereo microscope

XTX-4 step zoom stereo microscope

Step zoom Stereo microscope 1X/2X3X/4X/6X

1.Sharp stereo erect image over a wide field of view.
2.Upright binocular head with locked-in eyepiece.The left ocular-tube with diopter adjustment±5dp.The interpupillary distance is between 55-75mm.
3. XTX-4 series with fixed style objective 2X.
4.Pillar style stand.
5.CE approval.
6.Power supply 110V/60HZ or 220V/50HZ.
7. Each set packed in styrofoam box and in an inner box.Four sets in one outer carton.Optional accessories
1.Eyepiece:WF5×,WF10×,WF15×,WF20×
2.Ø95mm White/Black Working stage
3.Incandescent lamp 12V10W
4.Digital Camera
5.Darkfield Attachment and Jewel Tweezer for XTX-4C.
6.Wooden case or Aluminum carrying case.

ENQUIRY!
分类： , , 标签： , ,
描述

SPECIFICATION

 Model Eyepiece Objective Working Stage Illumination
XTX-4A WF10× Fixed 2× φ60 White/black Natural illumination
XTX-4B WF10× Fixed 2× φ60 White/black Incident illumination
XTX-4C WF10× Fixed 2× φ90  Frosted glass Incident illumination & transmitted illumination

OPTICAL DATA

Objective Eyepiece WD
5× 10× 15× 20×
M FOV M FOV M FOV M FOV
1× 5× 20.0mm 10× 20.0mm 15× 15.0mm 20× 10.0mm 57mm
2× 10× 10.0mm 20× 10.0mm 30× 7.5mm 40× 6.5mm 80mm
3× 15× 7.0mm 30× 6.7mm 45× 5.0mm 60× 4.3mm 61mm
4× 20× 5.0mm 40× 5.0mm 60× 3.7mm 80× 3.2mm 57mm
6× 30× 4.0mm 60× 3.3mm 90× 2.5mm 120× 2.1mm 66mm
