Standard Configuration
Model | XYX-M2003A | XYX-M2003B |
Eyepiece | Wide field WF10X(µ18mm) | |
Objective | Plan achromatic objectives with long working
distance (no cover glass) PL 5X/0.12 |
Plan achromatic objectives with long working
distance (no cover glass) PL 5X/0.12 |
Plan achromatic objectives with long working
distance (no cover glass) PL L10X/0.25 |
Plan achromatic objectives with long working
distance (no cover glass) PL L10X/0.25 |
|
Plan achromatic objectives with long working distance
(no cover glass) PL L40X/0.60 |
Plan achromatic objectives with long working distance
(no cover glass) PL L20X/0.40 |
|
Plan achromatic objectives with long working distance
(no cover glass) PL L60X/0.75 (Spring ) |
Plan achromatic objectives with long working distance
(no cover glass) PL L40X/0.60 |
|
Plan achromatic objectives with long working distance
(no cover glass) PL L60X/0.75(Spring ) |
||
Eyepieces tube | Trinocular,Inclination of 30˚, (Analyzer with field diaphragm to switch) | |
Vertical
illumination unit |
6V 20W, Halogen lamp, adjustable control | |
Vertical illumination With field diaphragm ,aperture diaphragm
and polarizer,(Y,B,G)filter and frosted filter |
||
Focus system | Coaxial coarse/fine focus system, with tensional adjustable and up stop,
minimum division of fine focusing: 2μm. |
|
Nosepiece | Quadruple Backward ball
bearing inner locating |
Quintuple Backward ball
bearing inner locating |
Stage | Double layer mechanical ( Size:185mmX140mm,movingrange:75mmX50mm) |
Optional accessories
Name | Sort/Technique parameter |
Eyepiece | Wide field WF16X(11mm) |
Dividing 10X(18mm) 0.1mm/Div | |
Objective | Plan achromatic objectives with long working distance
(no cover glass) PL L 50X/0.70 |
Plan achromatic objectives with long working distance
(no cover glass) PL L 80X/0.80 |
|
Plan achromatic objectives with long working distance
(no cover glass) PL L 100X/0.85 (Spring) |
|
Plan achromatic objectives (no cover glass)
PL 100X/1.25 (Spring, oil) |
|
CCD adapter | 0.4X |
0.5X | |
1X | |
0.5X with dividing 0.1mm/Div | |
Camera | DV-1 With USB & video output |
DV-2 With USB output | |
DV-3 With video output | |
Photo unit | 2.5X/4X Change over photograph attachment with 10X viewing eyepiece |
4X Focusing photograph attachment | |
MD Adapter | |
PK Adapter | |
Digital camera adapter
CANON(A610,A620,A630,A640) |
