ZTX-G 0.75-3.6X stereo microscope

ZTX-E 1-4X stereo microscope

Stereo microscope 1X-4X, zoom ratio: 1:4

45°inclined and 360°rotatable binocular head with locked-in eyepiece,Both ocular-tubes are with diopter adjustment ±5dp,The interpupillary distance is between 55-75mm.

Zoom  objective:1×-4×

ZTX-3E is trinocular.

Each set packed in styrofoam box and in an inner box.Two sets in one outer carton.

A wide range of accessories for selection.

Illumination:
L1:Incident reflected halogen light 12V 10W;Transmitted halogen light 12V 10W,Brightness is adjustable.
L2:Both incident and transmitted light with LED 1W,Brightness is adjustable.

ENQUIRY!
分类： , , 标签： , , ,
描述

OUTFIT

Viewing head  inclined at 45º
Zoom ratio 1:4
Eyepiece SWF10X/23mm
Objective 1x-4x
Magnification 10x-40
Interpupillary distance 55-75mm
Working distance 91mm
Working Stage φ95mm Frosted glass & White/Black Working stage
Height of Pillar 190mm
Travel distance 100mm
Diameter of Scope Holder φ76mm

OPTICAL DATA

Objective Standard spec Auxiliary Objective
0.5X 0.75x 1.5X 2X
Working Distance
91mm		 Working Distance
170mm		 Working Distance
42mm		 Working Distance
42mm		 Working Distance
28mm
Magnification Field of view
(mm)		 Magnification Field of view
(mm)		 Magnification Field of view
(mm)		 Magnification Field of view
(mm)		 Magnification Field of view
(mm)
WF5x/20mm 5x 20 2.5x 40 3.75X 25 7.5x 13 10X 10
20x 5 10x 11 15X 6.5 30x 3.5 40X 2.5
SWF10X/22mm 10x 23 5X 52 7.5X 30 15X 15 20X 11.5
40x 5.5 20X 12 30X 7 60X 4.8 80X 3
WF15X/15mm 15X 15.5 7.5X 36 11.2X 21 22.5X 10.5 30X 8
60X 4 30X 8.5 45X 5 90X 2.5 120X 2
WF20X/10mm 20X 10.5 10X 25 15X 14 30X 7 40X 5.5
80X 3 40X 5.8 60X 3.5 120X 1.8 160X 1.5

SPECIFICATION  LIST

Specification  Model
Parts Specifications ZTX-E-C3 ZTX-3E-C3 ZTX-E ZTX-3E ZTX-E-P
Eyepiece WF5X20 ○ ○ ○ ○ ○
SWF10X22 ● ● ● ● ●
WF15X15 ○ ○ ○ ○ ○
WF20X10 ○ ○ ○ ○ ○
Binocular ZTX-E ● ● ●
Trinocular ZTX-3E ● ● ○
Auxiliary
Objective		 0.5X/170mm ○ ○ ○ ○ ○
0.75X100mm ○ ○ ○ ○ ○
1.5X/42mm ○ ○ ○ ○ ○
2X/28mm ○ ○ ○ ○ ○
Stand C3 ● ● ○ ○ ○
E ○ ○ ● ● ○
P ○ ○ ○ ○ ●
TD-1 ○ ○ ○ ○ ○
TD-2 ○ ○ ○ ○ ○
Photographic device PH ○ ○ ○ ○ ○
CCD Mount CTV ○ ● ○ ● ○
Jewel Tweezer Ⅰ/Ⅱ ○ ○ ○ ○
Darkfield Attachment ASC ○ ○ ○ ○
Incident Light  Bowl Shape Halogen Lamp 12V10W ● ●
Transmitted Light Halogen Lamp 12V10W ● ●
LED Incident Light 1W ● ●
LED
Transmitted Light		 1W ● ●
Ring light RFL ○
Package Styrofoam +carton box ● ● ● ● ●
  • Standard  ○  Optional
