MIC-C610 dark field inverted metallurgical microscope
LCD screen, polarizing
| NAME | SPE | MIC-C610 |
| Viewing Head | 5-35° tilting head with side c port
interpupillary distance 48-75mm |
● |
| Eyepiece | High-point , extra wide field eyepiece EW10×/ 22, diopter
adjustable |
● |
| Infinite Plan
Metallurgical Objective |
5X, 10X,20X,50X,100X BD lens
Semi-apo lens optional |
● |
| Nosepiece | Quintuple nosepiece coded | ● |
| Stage | Double layer mechanical stage, 226x178mm, moving
range 50x50mm |
● |
| Focusing | Coaxial coarse & fine adjustment, Vertical objective movement,
Coarse stroke 37.7mm per rotation, Fine stroke 0.2mm per rotation Fine focus 0.002mm |
● |
| Kohler Illumination | 3W LED light
With LCD display with magnification display, light brightness memory, light temperature adjustment, and auto off |
● |
| Filter | Filter slide with simple polarizing kits. | ● |
