Global shutter technology:
The global shutter solves the distortion problem caused by the unsynchronized exposure of the pixel of the moving object, tracking and capturing the dynamic samples more precisely.
For example: with “real-time image stitching” technology offered by MIC TECH, customers can capture better image of the moving target.
Real time depth of filed stitching technology
Generally, the microscope only focuses on the shallow depth of field. In order to obtain a larger depth of field image, it is necessary to have multiple static images at different focal points been post-processed, which is difficult and cumbersome to operate.
But MIC TECH Mosaic 2.0 revolutionized software offers “real-time depth of field stitching technology ” by turning only the focus ring, then you can get a perfect picture with large depth of field. No need post-processing, no need to wait more time.
Product Model | MIChrome 5 Pro | MIChrome 20 | MIChrome 6 |
Shutter Mode | Global | Rolling | Rolling |
Sensor Model | IMX264LQR-C | IMX183CQJ-J | IMX178LQJ-C |
Sensor Type | CMOS | CMOS | CMOS |
Sensor Size | 2/3″ | 1″ | 1/1.8″ |
Color/Mono | Color | Color | Color |
Pixel Size | 3.45×3.45(μm) | 2.4×2.4(μm) | 2.4×2.4(μm) |
Resolution | 2448 (H ) x2048 (V ) | 5496(H)x3672(V) | 3072(H)x2048(V) |
Frame Rate | 35fps@5MP | 15fps@20MP | 40fps@6MP |
Exposure Settings | Support auto/manual exposure, exposure time: 0.13ms-15s | ||
Other Settings | Auto:color scale, white balance | ||
Manual: gain, noise reduction, gamma, flat field correction | |||
Color Temperature | 2000-15000K | ||
Picture Format | JPG/PNG/TIFF | ||
Data Interface | USB3.0 | ||
Optical Interface | Standard C Mount | ||
Multiple Cameras | Supports 4 Cameras Simultaneously | ||
PC Operating | Software: Mosaic V 2.0 System : Windows/Linux/Mac | ||
PC Configuration | CPU: Intel Core i5 or better(Quad or more Core),
RAM: 8G or more, OS: Windows 7/8/10 64bit |
||
Size & Weight | Size: 68x68x46mm Weight: 330g |
