SPECIFICATION
Viewing head | inclined at 45º |
Objective | 1X-2X-3X 1X-2X-4X |
Eyepiece | WF10X/20mm |
Magnification | 10X-20X-30X 10X-20X-40X |
Interpupillary distance | 55-75mm |
Working distance | 57mm |
Working Stage | φ70mm with clip and φ70mm Frosted glass & White/black board |
Height of Pillar | |
Travel distance | |
Base Size |
OPTICAL DATA
Model | Objective | Eyepiece | WD | |||||||
5X | 10X | 15X | 20X | |||||||
M | FOV | M | FOV | M | FOV | M | FOV | |||
XTX-9 | 1X | 5X | 20.0mm | 10X | 20.0mm | 15X | 15.0mm | 20X | 10.0mm | 57mm |
2X | 10X | 10.0mm | 20X | 10.0mm | 30X | 7.5mm | 40X | 6.5mm | ||
3X | 15X | 7.0mm | 30X | 6.7mm | 45X | 5.0mm | 60X | 4.3mm | 57mm | |
4X | 20X | 5.0mm | 40X | 5.0mm | 60X | 3.5mm | 80X | 3.2mm |
